Y-split Signal Distribution: The 1-to-2 male-female Y-split structure enables one female connector to transmit signals to two independent industrial modules, significantly reducing wiring complexity in automated production lines. By eliminating the need for bulky intermediate distribution boxes, this design saves critical panel space and minimizes the physical footprint of your cable routing architecture.
17-Pin Multi-Signal Support: With 17 pins, it handles power, control, and data signals simultaneously—perfect for multi-functional industrial devices like robotic arms or assembly line sensors. Consolidating multiple transmission lines into a single heavily shielded trunk reduces the overall cable weight and prevents tangling during continuous mechanical movement.
IP67 Harsh Environment Protection: Fully dustproof and water-resistant (1m water immersion for 30 mins), it resists oil splashes and humidity common in factories. The tactile, thick flame-retardant sealing ring provides a tight, secure fit that physically blocks micro-particulates and corrosive fluids from reaching the internal contact points.
Aviation-Grade Mechanical Strength: Follows aviation connector standards to endure 2,000+ vibration cycles (50-1500Hz) and 80N mechanical pressure, preventing loose connections in high-motion industrial setups. The heavy-duty aluminum alloy shell feels cool and solid to the touch, offering a rigid exterior that protects internal wiring from accidental impacts and heavy load stresses.
EMI Shielding: Integrated anti-electromagnetic interference design blocks interference from nearby motors or power cables, ensuring 99.9% signal accuracy. The internal metal shielding layer wraps the core wires entirely, preventing data loss or false triggering when routed alongside high-voltage power lines in dense machinery environments.
Market Research
The global industrial automation connector market is projected to reach 18.7B by 2028, with split-type connectors growing at 7.1% CAGR. A 2024 survey found 68% of manufacturing plants prioritize connectors that reduce wiring time—making the Y-split M12 model a top choice for modern facility upgrades. Facility managers recognize that complex, single-line wiring architectures consume excessive labor hours during installation and maintenance. Additionally, 82% of industrial buyers list IP67 waterproofing and EMI resistance as "must-have" features, as unplanned downtime from connector failure costs factories 2,000+/hour on average. By integrating these critical protective features into a single space-saving component, this connector directly addresses the most pressing operational vulnerabilities in contemporary heavy manufacturing and precision assembly sectors.
Performance Meets
Continuous Operation: Works stably for 10,000+ hours in -40°C to 85°C temperatures, matching the lifespan of most industrial equipment. Every batch undergoes a rigorous 48-hour salt spray test and high-frequency vibration testing to guarantee long-term reliability in extreme thermal and corrosive conditions.
Low Contact Resistance: Gold-plated pin contacts ensure contact resistance <5mΩ, minimizing power loss during high-current transmission. The pure copper core material provides exceptional conductivity, preventing localized overheating even when operating at maximum capacity over extended production shifts.
Quick Installation: Plug-and-play design cuts installation time by 50% compared to screw-lock connectors, ideal for urgent production line upgrades. The satisfying mechanical click upon insertion confirms a secure lock, allowing technicians to perform rapid blind-mating in tight, hard-to-reach machine enclosures.
Global Compliance Standards: Achieves strict adherence to international safety benchmarks, holding CE, RoHS, and UL certifications. This ensures the component meets the rigorous entry requirements for global industrial automation projects, providing peace of mind regarding electrical safety and environmental responsibility.
Specification Information
Precision engineering dictates every aspect of this component's physical and electrical profile. Built in strict accordance with the IEC 61076 international standard, this connector guarantees exact dimensional tolerances. This standardization ensures it acts as a direct, interchangeable replacement for existing infrastructure, mating perfectly with mainstream industrial sensors, actuators, and PLC modules without requiring physical modifications. The combination of an aluminum alloy exterior and precision injection molding creates a structural integrity designed specifically for the daily physical abuse of factory environments.
Parameter
Detail
Model
M12
Brand
SUYI
Pin Count
17
Split Type
1-to-2 Male-Female Y-split
Waterproof Rate
IP67
Material
Aluminum alloy (shell)
Current Rating
3A per pin
Voltage Rating
250V AC/DC
Application Fields
Industrial Robots: Connects robotic arms to control systems and sensors, transmitting power and position signals simultaneously. The secure locking thread prevents the connection from vibrating loose during the rapid, repetitive multidirectional movements typical of welding or pick-and-place robotics.
Automated Assembly Lines: Distributes signals to multiple conveyor belt motors and quality inspection cameras. The Y-split design allows facility engineers to branch out connections directly at the machine level, avoiding the need to run separate long-distance cables back to the main control panel.
Food & Beverage Factories: Resists water and cleaning agents, used in packaging machines and temperature sensors. The IP67 rating ensures that daily high-pressure washdowns and exposure to harsh sanitizing chemicals will not compromise the internal circuitry or cause electrical shorts.
Renewable Energy: Applied in solar panel inverters and wind turbine control units, withstanding outdoor humidity. The wide operating temperature range and oxidation-resistant materials maintain consistent power delivery despite exposure to morning dew, freezing rain, and intense UV radiation.
Comprehensive Support & Customization
OEM/ODM Customization: We understand that standard configurations do not fit every facility layout. We support flexible customization of cable lengths, jacket materials (such as abrasion-resistant PUR or cost-effective PVC), specific pin definitions, and custom logo engraving to match your unique non-standard wiring requirements.
Supply Chain & Delivery: Backed by large-scale production capabilities and systematic inventory tracking, we guarantee stable bulk availability. Every shipment is secured in industrial-grade anti-static and impact-resistant packaging, ensuring components arrive in pristine condition, ready for immediate deployment.
After-Sales & Technical Support: Our engineering team provides end-to-end assistance, from initial component selection and wiring layout optimization to post-installation troubleshooting. Backed by a long-term warranty, we actively help you reduce maintenance risks and keep your operations running smoothly.
